Flashforge WJ51C Overview
- Compact Footprint865 × 510 × 654 mm (W × D × H)
- Custom-Level Precision2900 × 2900 × 1700 DPI; layer thickness 15 µm
- Industrial-Grade Output3 kg per month per unit
The WJ51C combines high toughness wax material with precise performance to reduce defects and ensure reliable casting results. It enables on demand loading with small wax blocks, improving material utilization up to 55 percent and lowering costs. The machine delivers smooth, accurate models that reduce post processing work by around 30 percent. Its industrial grade design supports continuous operation while offering 30 to 50 percent lower overall operating costs.
Add What You Need, Produce What You Need
Use small wax blocks for precise, on-demand loading. Add only what is needed, exactly when it is needed. Flexible and efficient, with material utilization of 55% or more, effectively reducing wax consumption costs.
Unbeatable Value, Worry-Free Stability
An industrial-grade, stable design supports continuous 24/7 operation. Compared with competitors offering similar precision, total operating costs are 30%–50% lower.
Enhanced Precision, Minimal Post-Processing
Achieve superior model accuracy with a smooth, refined surface finish. Say goodbye to tedious polishing, saving approximately 30% in labour and post-processing costs.
Dedicated Wax: Strength Meets Toughness
The WJ51C uses a dedicated high-toughness wax material, reducing defect rates during casting and providing an ideal foundation for subsequent processes.
Sample Prints & Materials
WJ51C Specifications
| Specification | Details |
|---|---|
| Print Technology | MultiJet Printing (MJP) |
| Build Volume | 235 × 138 × 100 mm |
| Resolution | 2900 × 2900 × 1700 DPI; Layer Thickness: 15 µm |
| Dimensional Accuracy | ±0.04 mm / 20 mm |
| Material Utilization | Part wax utilization rate ≥57% |
| Print Speed | Single-channel: 7 mm/h; Dual-channel: 3.5 mm/h |
| Slicing Software | WaxJetPrint |
| Supported File Format | STL / SLC |
| Connectivity | Network 10/100/1000 Ethernet; USB (Wi-Fi expandable) |
| Operating System | Windows 10 / Windows 11 (64-bit) |
| Power Supply | AC 100–250V, 50–60Hz, 2.2 kW |
| Operating Environment | Temperature: 18–26°C; Humidity: 30–70% |
| Equipment Dimensions | 865 × 510 × 654 mm |
| Equipment Weight | 115 kg |
| Packaging Dimensions | 1020 × 660 × 905 mm |
| Packaging Weight | 140 kg |
Material Specifications
| Specification | FFWJ1200 | FFMS3200 |
|---|---|---|
| Material Type | Part Material | Support Material |
| Net Weight | 72 g/block | 180 g/block |
| Composition | 100% Wax | Wax Support Material |
| Color | Red | White |
| Density @90°C (Liquid) | 0.79 g/cm³ | 0.79 g/cm³ |
| Melting Point | 68°C | 55°C |
| Softening Point | 63°C | — |
| Volumetric Shrinkage | 1.10% | — |
| Linear Shrinkage | 0.70% | — |
| Needle Penetration | 9 | — |
| Ash Content | < 0.01% | — |
| Description | High-precision castable wax material | Hands-free dissolvable support material |
Related Products
Flashforge WJ51C FAQs
The WJ51C combines high toughness wax material with precise performance to reduce defects and ensure reliable casting results. It enables on demand loading with small wax blocks, improving material utilization up to 55 percent and lowering costs. The Flashforge WJ51C is part of our Jewellery 3D Printer range.
Key specifications of the Flashforge WJ51C: Build Volume: 235 × 138 × 100 mm; Print Speed: Single-channel: 7 mm/h; Dual-channel: 3.5 mm/h; Net Weight: 72 g/block 180 g/block; Print Technology: MultiJet Printing (MJP); Resolution: 2900 × 2900 × 1700 DPI; Layer Thickness: 15 µm. The full specification table is shown above on this page.
The Flashforge WJ51C price depends on the configuration you choose and current rates. For an up-to-date quote, call or WhatsApp +91 9130528227, or send an enquiry using the form below, where the Flashforge WJ51C is already selected.
You can buy the Flashforge WJ51C directly from AS Technology. We supply customers across India from our Mumbai head office and branch offices in Delhi, Bengaluru, Hyderabad, Ahmedabad, Surat, Jaipur and Rajkot. Find your nearest office.
Depending on your production needs, you may also want to compare the Flashforge WaxJet 510 3D Printer, Flashforge WaxJet 530 3D Printer and ProJet MJP 2500W Printer. See the full Jewellery 3D Printer range to compare every model.
